M-308L AWS A5. 9-07 : ER308L
by KISWEL
Welding of low carbon 18%Cr-8%Ni steel such as AISI Types 304L and 308L
AWS:
A5.9 : ER308L
Specification
Key Features
| Sizes (mm) | Standard | Welding Position | Shielding gas | Polarity | |
|---|---|---|---|---|---|
| 0.8~1.6 | AWS A5.9 EN 14343 A EN 14343 B KS D 7026 JIS Z 3321 |
ER308L W 19 9 L SS308L Y308L Y308L |
F, HF | Ar | DC(+) |
| Typical chemical composition of wire (%) | ||||||||
|---|---|---|---|---|---|---|---|---|
| C | Si | Mn | P | S | Cr | Ni | Mo | Remark |
| 0.02 | 0.49 | 1.62 | - | - | 19.77 | 9.61 | 0.16 | - |
| Typical mechanical properties of all-weld metal | |||||
|---|---|---|---|---|---|
| Y.S (MPa) | T.S (MPa) | EI. (%) | Hardness (HV) | IV (J) | PWHT |
| 390 | 580 | 40 | - | 90 (0℃) 60 (-196℃) |
- |
Product Dimensions and Weld Current Range
| Welding Position |
Sizes (mm) | Ampere (A) | Volt (V) | ||
|---|---|---|---|---|---|
| Min. | Max. | Min. | Max. | ||
| F, HF | 0.9mm | 70 | 250 | 14 | 25 |
| F, HF | 1.2mm | 100 | 300 | 16 | 32 |
| F, HF | 1.4mm | 120 | 320 | 16 | 34 |
